DOUBLE DECKER

ALFA D2 ROOF MOUNTED UNIT DESIGNED FOR DOUBLE DECKERS



 3 independent subunits to assure accurate and independent regulation of each separate compartments of the coach  Continuous dedicated control air flow for each compartments, to achieve independent regulation of each compartments of the coach Dedicated cooling/heating control modulation for each compartments of the coach  efficient air filtration. Both for fresh than recirculated air
flow.  Anti ice control during cooling.  Safe heating functioning  Reliable components.





Cooling Capacity kW 36 (12x3)
Refrigerant Circuits n° 3
Summer Design condition °C/R.H. 40/40
Extreme summer Condition °C 45
Electrical supply in Cooling V/Hz 400/50
Max electrical consumption in Cooling kVA 24
Max Inrush Current A 90
HFC Refrigerant R407C
Heating Capacity kW 30
Heating stages n° 6
Winter Design Condition °C -20
Extreme winter Condition °C -25
Electrical Supply in Cooling V/Hz 400/50
Max Electrical Consumption in Heating kVA 34
Auxiliary Electrical supply V 24
Total Air Flow m3/h 3600
Total Air Flow (free blowing) m3/h 4800
Air Static Pressure Pa 500
Overall Dimensions mm 3200 x 1650 x 800
Weight kg 720
