FA V3  ROOF MOUNTED UNIT FOR MAIN LINE & HIGH SPEED

 Pressure wave protection devices integrated in the units in case of high speed application Continuous air flow control to improve quality of regulation, noise parameters and decrease precooling and preheating time  Continuous fresh air control to optimize energy consumption and precooling and preheating performance Low weight efficient air filtration. Both for fresh than recirculated air flow.

Cooling Capacity kW 36
Refrigerant Circuits n° 2
Summer Design condition °C/R.H. 40/40
Extreme summer Condition °C 45
Electrical supply in Cooling V/Hz 400/50
Max electrical consumption in Cooling kVA 22
Max Inrush Current A 110
HFC Refrigerant R407C
Heating Capacity kW 30
Heating stages n° 2
Winter Design Condition °C -20
Extreme winter Condition °C -25
Electrical Supply in Cooling V/Hz 400/50
Max Electrical Consumption in Heating kVA 32
Auxiliary Electrical supply V 24 dc
Total Air Flow m3/h 3600
Total Air Flow (free blowing) m3/h 4800
Air Static Pressure Pa 450
Overall Dimensions mm 3200 x 1650 x 550
Weight kg 650
